Nominal Diameter(mm) :

2"(50mm)

Pressure Range B1600 :

0 to 160 inH2O / B1800: 0 to 18 Psi

Displacement (mm) :

1.1~1.4

Accuracy (%) :

±(2- 1.5-2)%

Resolution B1600 :

1 inH2O / B1800: 1 Psi

भार क्षमता

Static Load ≤ Full Scale

Fluctuating Load ≤ 90% Full Scale

Overload Safety Value ≤ 125% Full Scale

काम का माहौल

Operating Temperature: 32 to 104°F(0 to 40°℃)

Storage Temperature: 14 to122°F(-10 to 50°C)

Relative humidity ≤ 80%

तापमान का प्रभाव

Accuracy at temperature above and below the reference temperature (20°C)

will be effected by approximately ±0.4% per 10°C of full scale

संबंध

Thread , 1/4"NPT (available upon request)

Hose Length :  50"(1.27m)

फिटिंग

निचला माउंट (एल)

मापने वाला तत्व

Capsule :  Beryllium copper

Movement :  Copper alloy

Dial :  Aluminum, White letters on black background

(अनुरोध पर उपलब्ध)

Pointer :  Aluminum,White,(available upon request)

Case :  Plastic

Window : पीसी
