Model

YEY-70

Nominal Diameter (mm)
70

Dial Size (mm)
63.5

Pressure Range
Item No：19007 --- -60~0~+60cmH2O

Displacement (mm)
1.1~1.4

Accuracy (%)
2-1-2

Load Capacity
Static Load                 ≤ Full Scale
Fluctuating Load         ≤ 90% Full Scale
Overload Safety Value ≤ 125% Full Scale

Working Environment
Ambient Temperature -25°C ~55°C
Medium max.            +55°C
Relative humidity       ≤ 80%

Temperature Influence
Accuracy at temperature above and below the reference temperature (20°C) will be effected by approximately ±0.4% per 10°C of full scale

Connection
Brass electroplating
Threadless (Sealing ring connection)

Fitting
Lower Mount (L)
Center Back Mount (C)

Measuring Element
Capsule : Beryllium copper
Movement : Copper alloy

Zero Adjustment
Front / Back(available upon request)

Dial
Aluminum, style and color available upon request

Pointer
Aluminum, style and color available upon request

Case
Carbon steel electroplating

Bayonet Ring
Carbon steel electroplating

Window
PC
