Model

C+H Ø45/56/83/110B

Nominal Diameter (mm)
45/56/83/110

Pressure Range
Item No：2005---C+H Ø45B---0-25~100 kPa
Item No：2006---C+H Ø56B---0-10~100 kPa
Item No：2007---C+H Ø83B--- 0-1~10 kPa
Item No：2008---C+H Ø110B---0-0.4~10kPa

Displacement (mm)
1.1~1.4

Accuracy (%)
1；1.6；2.5

Load Capacity
Static Load ≤ Full Scale
Fluctuating Load ≤ 90% Full Scale
Overload Safety Value ≤ 125% Full Scale

Working Environment
Ambient Temperature -25°C ~55°C
Medium max. +55°C
Relative humidity ≤ 80%

Tmperature Influence
Accuracy at temperature above and below the reference temperature (20°C) will be effected by approximately ±0.4% per 10°C of full scale

Measuring Element
Diaphragm : 316 L SS
Base plate : 316 L SS

Fitting
M5 (Sealing ring connection)
